Wiring color codes (primary colors)
black | VC |
brown | BR |
reddish brown | T |
red | R |
pink | RK |
orange | ABOUT |
yellow | Y |
dark green | DG |
light green | LG |
blue | DB |
blue | LB |
purple | R |
grey | GY |
white | W |
strokes | (H) |
points | (D) |
The presence of a tracking mark on the wire is determined by the second color and the letter - "H" for hatching, "D" - for points. If letters are absent, stripes are implied.
